Hastelloy C22 Pipes and Tubes are readily available at Gautam tubes. We are an acknowledged manufacturer of the industry that also exports the pipes and tubes across the globe. Pipes and tubes are the need of every sector of industry such as petrochemical, construction, oil and gas, hydropower plants, food processing and more. Hence, they should be of appropriate dimensions and specifications. A pipe is a vital component of the piping industry thus they should be available in all nominal as well as customized sizes. Gautam tubes ensure this need of customers irrespective of the field in which they are going to be used.
These tubes are formed from a process such as gas metal-arc, gas tungsten-arc, and shielded metal-arc. Most of the industries mentioned above have corrosive, reducing, and even oxidizing environments. These environments are mixed with chemicals and acids that harm the equipment, pipes, and tubes. Therefore, special grades are used for their manufacturing. The Hastelloy C22 has excellent properties to serve in any of the above-mentioned environments. It shows excellent resistance even at elevated and cold temperature.
The alloy C22 contains molybdenum, tungsten, chromium, and nickel alloy hence it is known as a versatile austenitic alloy. The resistance properties are acquired by these contents in pipes and tubes. In oxidizing media, resistance is due to the chromium content whereas in reducing media it is due to tungsten. Nickel offers resistance in aqueous media making the Hastelloy C22 Pipes and Tubes useful in multi-purpose plants. No effects by wet chlorine, acetic acids, cupric chlorides, ferric, seawater, brine, organic and inorganic solutions are seen.
Hastelloy C22 Pipe & Tube Supplier, Hastelloy C22 Pipes and Tubes Manufacturer, Hastelloy C22 ERW Tubes Price List, Hastelloy C22 Pipes and Tubes Exporter in Mumbai, India.
However, the pipes and tubes made of this alloy are not suitable to work at a temperature above than 1250 degree F. at this temperature detrimental phase’s start forming. In most of the chemical process applications, these products offer excellent performance even in the welded condition. They are not affected in this zone as grain boundary precipitation is not formed due to the presence of nickel alloy. Excellent resistance against stress corrosion, crevice corrosion, and pitting resistance is offered by the Hastelloy C22 Pipes and Tubes.
Standard Specification and Size Range of Hastelloy C22 Pipe and Tube
Specifications : ASTM B622, B619, B626 / ASME SB622, SB619, SB626
Dimension Standard : ASTM, ASME and API
Size Range : 15"NB – 150"NB
Schedule :SCH 10 – SCH XXS
Type : Seamless / ERW / Welded / Fabricated / CDW
Length : Single Random, Double Random & Cut Length.
Form : Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, "U" Shape, Pan Cake Coils, Hydraulic Tube
End : Plain End, Beveled End, Treaded
Hastelloy C22 Seamless Pipes
Hastelloy Alloy C22 Seamless Pipe, UNS N06022 Seamless Pipes, DIN 2.4602 Seamless Pipe
Hastelloy C22 Seamless Tubes
Alloy UNS N06022 Seamless Tubes, Hastelloy 2.4602 Seamless Tubes, ASTM B165 Hastelloy C22 Seamless Tubing
Hastelloy C22 Welded Pipes
Hastelloy Alloy C22 Welded Pipes, Hastelloy N06022 Welded Pipe, DIN 2.4602 Welded Pipes
Hastelloy C22 Welded Tubes
Hastelloy Alloy C22 Welded Tube, Hastelloy N06022 Welded Tubes, DIN 2.4602 Welded Tubes, ASTM B730 Hastelloy C22 Welded Tubing
Hastelloy C22 ERW Pipes
Hastelloy N06022 ERW Pipes, Hastelloy Alloy 2.4602 ERW Pipes, Hastelloy Alloy C22 ERW Pipes
Hastelloy C22 ERW Tubes
Hastelloy Alloy N06022 ERW Tubes, Hastelloy 2.4602 ERW Tubes, Hastelloy C22 ERW Tubing
Chemical Composition of Hastelloy Grade C22 Pipes & Tubes
Grade | C | Mn | Si | S | Co | Fe | Ni | Mo | P |
Hastelloy C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.5 max | 2-6 | Bal | 12.5-14.5 | 0.02 max |
Mechanical Properties of Hastelloy C22 Pipes & Tubes
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000, MPa – 690 | Psi – 45000, MPa – 310 | 45 % |
