Gautam Tubes is the prime manufacturer and supplier of the Incoloy 800/800h/800ht Pipes & Tubes. We make these pipes and tubes with utmost care and dedication so that clients can easily use them in various applications. We are working in this field for a long time and so we know how to meet our clients need. We make a good quality product using the raw material which is tested and certified. We make sure there is no impurity in our product.
Incoloy 800/800h/800ht is a nickel-iron-chromium alloy which is known for its good strength as well as excellent resistance to carburization and oxidation in elevated temperature environment. The nickel steel alloy is similar except for the high level of carbon in 800 H and the addition of 1.20% aluminum and titanium in 800 Ht. Incoloy 800 was modified to 800H to control carbon as well as grain size. This helped in optimizing the stress rupture properties. It is further modified to 800 Ht and titanium and aluminum is combined to offer high-temperature properties.
The nickel content of this alloy offers resistance to chloride stress corrosion cracking and embrittlement from precipitation. The general resistance to corrosion of this alloy is also excellent. It shows superior creep strength.
It is used in an application where temperature requirement is up to 110 degrees F. Incoloy 800/800h/800ht Pipes & Tubes also show resistance to oxidation as well as nitriding atmosphere.
Incoloy 800 ERW Tubes Price List, Incoloy 800HT Pipe & Tube Supplier, Incoloy Alloy 800H Pipes and Tubes Exporter in Mumbai, India.
Incoloy 800/800h/800ht also show best cold forming characteristics. When cold formed the grain size produced an undulated surface called as orange peel. Incoloy 800/800h/800ht can be welded by common methods which are used on the stainless steel. One can easily use Incoloy 800/800h/800ht Pipes & Tubes in pressure vessels, industrial furnaces, and heat-treating equipment and so on. All these features are offered in Incoloy 800/800h/800ht Pipes & Tubes manufactured by us. To ensure that there is no comprise on the quality we perform the various testing process. Thus, the product which comes out is perfect. We deliver the Incoloy 800/800h/800ht Pipes & Tubes to our customers fast and in good condition.
Standard Specification and Size Range of Incoloy 800/800H/800HT Pipe and Tube
Specifications : ASTM B167, B517, B516 / ASME SB167, SB517, SB516
Dimension Standard : ASTM, ASME and API
Size Range : 15"NB – 150"NB
Outer Diameter : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Thickness Range : 0.3mm – 50 mm, 1MM TO 3 MM 0.028 TO 0.156 IN, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type : Seamless / ERW / Welded
Length : Single Random, Double Random & Required Length
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
End : Plain End, Beveled End, Treaded
Incoloy 800/800H/800HT Seamless Pipes
Incoloy Alloy 800/800H/800HT Seamless Pipe, UNS N08800/N08810/N08811 Seamless Pipes, DIN 1.4876/1.4958/1.4859 Seamless Pipe
Incoloy 800/800H/800HT Seamless Tubes
Alloy UNS N08800/N08810/N08811 Seamless Tubes, Incoloy 1.4876/1.4958/1.4859 Seamless Tubes, ASTM B167 Incoloy 800/800H/800HT Seamless Tubing
Incoloy 800/800H/800HT Welded Pipes
Incoloy Alloy 800/800H/800HT Welded Pipes, Incoloy N08800/N08810/N08811 Welded Pipe, DIN 1.4876/1.4958/1.4859 Welded Pipes
Incoloy 800/800H/800HT Welded Tubes
Incoloy Alloy 800/800H/800HT Welded Tube, Incoloy N08800/N08810/N08811 Welded Tubes, DIN 1.4876/1.4958/1.4859 Welded Tubes, ASTM B516 Incoloy 800/800H/800HT Welded Tubing
Incoloy 800/800H/800HT ERW Pipes
Incoloy N08800/N08810/N08811 ERW Pipes, Incoloy Alloy 1.4876/1.4958/1.4859 ERW Pipes, Incoloy Alloy 800/800H/800HT ERW Pipes
Incoloy 800/800H/800HT ERW Tubes
Incoloy Alloy N08800/N08810/N08811 ERW Tubes, Incoloy 1.4876/1.4958/1.4859 ERW Tubes, Incoloy 800/800H/800HT ERW Tubing
Chemical Composition of Incoloy Grade 800/800H/800HT Pipes & Tubes
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
Mechanical Properties of Incoloy 800/800H/800HT Pipes & Tubes
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
