Gautam Tubes cater raw materials like ASTM A671 and process ASTM A 671 Welded Pipe & Tubes. We have a long track record for manufacturing welded pipes and tubes. We got expertise in producing high tensile welded pipe and tubes that are known for its prominent features. We also deal with other types of ferrous and non-ferrous welded pipes and tubes. In our inventory, we stock these pipes and tubes in various custom dimensions and surface finishes. We also offer nonstandard dimensions and provided machining allowances for multiple applications. Here we decrease possibilities of manufacturing defected pipes and tubes this is due to our well-organized manufacturing plants and manufacturing machines. We follow industrial set guidelines and norms to manufacture a superior level of products.
ASTM A671 Welded Pipe & Tubes do not have weld seam inside or outside of its surface. Mostly, welded pipes and tubes are produced by electric resistance welding operations; however, any type of standard welding operations can be applied to it. These pipes and tubes are processed from flat ASTM A671 sheets. First, these are cold formed into a cylindrical shape and then welded from its longitudinal ends.
A 671 Welded Pipe & Tubes are designed for lower to higher corrosion resistance rates in a wide range of fluctuating temperatures. It has great alloying chemistry that enables optimum corrosion resistance property. However, these pipes and tubes offer great resistance to pitting and crevice corrosion cracking. These pipes and tubes are intended to use in chemical containing environments such as chlorides, harsh acids, and other severe chemical compounds.
ASTM A671 Carbon Steel Tubes, ASTM A671 Carbon Steel EFW Pipe Distributors, ASTM A671 Welded Steel Pipes Price List, ASME SA 671 Pipes & Tubes, ASTM A671 Welded Pipes & Tubes Exporter in Mumbai.
ASTM A671 has great resistance to organic elements. Ideally, it can serve good service in lower temperatures. It has alloying elements such as manganese, silicon, moderate carbon content. This make stabilized microstructure of alloy and provide excellent properties. A 671 has good cold work hardening rate makes it machinable ideally with standard machines and operations. It requires standard speeds and cut depths for machining. ASTM A671 Welded Pipe & Tubes are used in piping systems that works at high pressure. Therefore, the products are designed to withstand such a critical pressure without any damage.
Standard Specification and Size Range of ASTM A671 Welded Steel Pipe & Tubes
Specifications : ASTM A671 / ASME SA671
Dimensions : ASTM, ASME and API
Size : 1/2” NB to 36” NB
Outer Diameter Size : 16" NB To 100" NB (Nominal Bore Size)
Thickness : Schedule 20 To Schedule XXS (Heavier On Request) Up to 250 mm Thickness
Schedule : SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
Type : Welded / EFW (Electric Fusion Welded Pipes)
Form : Round Pipe & Tube, Square Pipe & Tube, Rectangular Pipe & Tube
Length : max 16000mm, Single Random, Double Random & Cut Length or As per customer's
ASTM A671 Pipe Grades : ASTM A671 Grade CC60, ASTM A671 Grade CC65, ASTM A671 Grade CC70
ASTM A671 Class : CLASS 10, 11, 12, 13, 20, 21, 22, 23, 30, 31, 32, 33, 40, 41, 42
End : Plain End, Beveled End, Treaded
ASTM A671 Welded Pipe
Carbon Steel A671 Pipe, ASTM A671 Steel Welded Pipes, ASME SA671 Welded Pipes, ASTM A671 Round Pipe
ASTM A671 Tubing
Carbon Steel ASTM A671 Tubes, ASTM A671 Welded Tubing, ASME SA671 Round Tube
ASTM A671 EFW Pipe
Carbon Steel ASTM A671 EFW Pipe, ASTM SA671 EFW Steel Pipes
Chemical Composition of ASTM A671 Carbon Steel Pipes & Tubes
ASTM A671 Specification | ASTM A671 Steel grade | ASTM A671 Chemical composition | ASTM A671 Remarks | |||||
C | Si | Mn | P | S | Ti | |||
Pipes for pressure service ASTM A671, A672 |
-/A45 | -/0.17 | - | 0.98 | 0.035 | 0.035 | - | A671/ A672 |
-/A50 | -/0.22 | - | ||||||
CA55/A55 | 0.28 | - | ||||||
-/B55 | -/0.20 | 0.13 ~0.45 |
||||||
CB60/B60 | 0.24 | |||||||
CB65/B65 | 0.28 | |||||||
CB70/C70 | 0.31 | 1.30 | ||||||
-/C55 | -/0.18 | 0.55 ~0.98 |
||||||
CC60/C60 | 0.21 | |||||||
CC65/C65 | 0.24 | 0.79 ~1.30 |
||||||
CC70/C70 | 0.27 |
Mechanical Properties of ASTM A671 Steel Pipe & Tube
Specification | Steel Grade | BASE METAL MECHANICAL COMPOSITION | Welding point tensile strength (N/mm2) | Remarks | |||
Yield point (N/mm2) | Tensile Stregth (N/mm2) | Test Pieces | Elongation (%) | ||||
Pipes for pressure service ASTM A671, A672 | -/A45 | -/165 | -/310~450 | - | -/30 | -/310~450 | A671/ A672 |
-/A50 | -/185 | -/345~485 | -/28 | -/345~485 | |||
CA55/A55 | 205 | 380~515 | 27 | 380~515 | |||
-/B55 | -/205 | -/380~515 | -/27 | -/380~515 | |||
CB60/B60 | 220 | 415~550 | 25 | 415~550 | |||
CB65/B65 | 240 | 450~585 | 23 | 450~585 | |||
CB70/B70 | 260 | 485~620 | 21 | 485~620 | |||
-/C55 | -/205 | -/380~515 | -/27 | -/380~515 | |||
CC60/C60 | 220 | 415~550 | 25 | 415~550 | |||
CC65/C65 | 240 | 450~585 | 23 | 450~585 | |||
CC70/C70 | 260 | 485~620 | 21 | 485~620 |
People Also Searched For
asme sa 671 welded carbon steel pipe, astm a 671 pipe & tubes manufacture, astm a671 welded carbon steel tubing, welded astm a671 tubing, astm a671 / a671m welded carbon steel pipe for low-temperature service, astm a671 welded schedule 40 pipe low cost, astm a671 schedule 40 pipe, astm a671 pipe material, astm a671 for lower temperatures electric fusion welded steel pipes, carbon steel pipe and tube astm a 671, astm a671 cc70 efw pipe, astm a671 pipe dimensions, astm a 671 gr cc60 cl22, astm a671 pipe properties, asme sa 671 welded carbon steel tube, astm a671 pipe standards, astm a671 pipe specification, astm a671 pipe pressure rating, astm a671 cc60 / cc65 / cc70 efw welded pipe dealer, astm a671 cc65 efw pipe, astm a671 pipe sizes, astm a671 welded steel pipe, astm a671 cc60 pipe, astm a671 pipe schedule chart, tuberia astm a671, astm a671 welded carbon steel pipe price list, astm a 671 tubes supplier, carbon steel a671 welded pipe, astm a671 welded tubes exporters, astm a671 tube suppliers, astm a671 welded steel tube, astm a671 welded pipe dimensions, astm a671 carbon steel tubing, astm a671 pipe suppliers, astm a671 carbon steel pipe exporter, astm a671 pipe sizes, astm a671 pipe thickness, astm a671 welded pipe wall thickness.
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- ASTM A671 Pipe & Tube uses in Plumbing
- ASTM A 671 Pipe & Tubes uses in Heating
- ASTM A671 Welded Pipe & Tube uses in Water Supply Systems
- ASME SA671 Welded Pipe & Tube uses in Paper & Pulp Industry
- Welded Carbon Steel ASTM A671 Pipes and Tubes uses in General Purpose Applications
- ASTM A671 EFW Carbon Steel Pipes and Tubes uses in Fabrication Industry
