Gautam Tubes, a recognized manufacturer has been in the industry since its establishment in the year 1984. We, since our establishment, are serving the customers with enhanced quality of pipes and tubes. We have a complete team that is engaged in the production of the pipes and tubes to serve the customer’s demands with no errors. Errors products are not welcomed at our company; therefore, we even inspect the raw materials before beginning with the production. Our ASTM A519 & ASME SA519 Tubes have thus exceptional performance which makes them an ideal product for dealing in high-pressure applications.
Often, the pipes and tubes are considered as same as they are used interchangeably. However, the tubes are different from the pipes in the term that they are the main product used for structural purposes. This is only a fundamental difference in the two which is usually considered while measuring the size of the product. Both have common sizing dimensions when it comes to outside, wall and inside diameter.
Tubes don’t have a specifically round structure and usually seam or welded to fix the joints. The tubes have to be stronger as they have to carry weight; therefore, the grade that offers higher strength is preferred for construction. The ASTM and ASME SA519 tubes have rigid construction that makes it suitable for high pressure and temperature bearing applications. Our manufactured tubes don’t undergo deformation therefore considered as a safer product as boiler equipment. Their excellent features offer tight fittings which ensure no leakages even at high-pressure conditions.
ASTM A519 Carbon Steel Tubing Distributors, ASME SA519 Seamless Tubes, ASTM A519 Steel Tubes Price List, ASTM A519 / ASME SA519 Seamless Tubing, ASME SA / ASTM A519 Mechanical Tubes, ASTM S/A 519 Tubes Exporter in Mumbai.
The mechanical tubing of the alloy gives it resilience and strength that make them useful in bridge construction, building, more frequently. The tubing of the alloy makes a competitive product to be used in heat exchanging applications. Annealing is usually required to process at 2050 degree F which is rapidly air cooled or water quenched. Optimum corrosion resistance is ensured by the hot working process. The alloy offers high hardening rate which is possible with the use of rigid, overpowered machines that perform efficient machining. We have all the efficient tools and machines to feed our customers with superior quality ASTM A519 & ASME SA519 Tubes.
Standard Specification and Size Range of ASTM A519 & ASME SA519 Tubes
Specifications : ASTM A519 / ASME SA519
Standards : ASTM, ASME and API
Size : ½”-24” and Nominal bore NB sizes 15NB-600NB
Schedule : SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
Type : Seamless and Mechanical Tubing
Form : Round Tube, Square Tube, Rectangular Tube
Length : Single Random, Double Random & Cut Length or As per customer's
End : Plain End, Beveled End, Screwed, Treaded
ASTM S/A 519 Seamless Tubes
ASTM A519 Carbon Steel Seamless Tubing, ASTM A519 Gr 1026 Seamless Tubes, SA / A519 GR.4130 Seamless Tubes, ASME SA519 GR.4140 Seamless Tubes
ASME SA519 Mechanical Tubing
ASTM A519 Carbon Steel Seamless Mechanical Tubing, ASTM A519 Gr 1026 Mechanical Tubing, SA / A519 GR.4130 Mechanical Tubes, ASME SA519 GR 4140 Mechanical Tubing
Chemical Composition of ASTM A519 Carbon Steel Tubes
Steel Grade | Chemical Composition Limits (%) | ||||||
C | Mn | P Max. | S Max. | Si | Cr | Mo | |
MT 1010 | 0.05-0.15 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
MT 1015 | 0.10-0.20 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
MT X 1015 | 0.10-0.20 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
MT 1020 | 0.15-0.25 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
MT X 1020 | 0.15-0.25 | 0.70-1.00 | 0.040 | 0.050 | - | - | - |
1008 | 0.10 | 0.30-0.50 | 0.040 | 0.050 | - | - | - |
1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1012 | 0.10-0.15 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1015 | 0.13-0.18 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1016 | 0.13-0.18 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1017 | 0.15-0.20 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1019 | 0.15-0.20 | 0.70-1.00 | 0.040 | 0.050 | - | - | - |
1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1021 | 0.18-0.23 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1022 | 0.18-0.23 | 0.70-1.00 | 0.040 | 0.050 | - | - | - |
1025 | 0.22-0.28 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1030 | 0.28-0.34 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1035 | 0.32-0.38 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1040 | 0.37-0.44 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1045 | 0.43-0.50 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1050 | 0.48-0.55 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1518 | 0.15-0.21 | 1.10-1.40 | 0.040 | 0.050 | - | - | - |
1524 | 0.19-0.25 | 1.35-1.65 | 0.040 | 0.050 | - | - | - |
1541 | 0.36-0.44 | 1.35-1.65 | 0.040 | 0.050 | - | - | - |
4118 | 0.18-0.23 | 0.70-0.90 | 0.040 | 0.040 | 0.15-0.35 | 0.40-0.60 | 0.08-0.15 |
4130 | 0.28-0.33 | 0.40-0.60 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
4135 | 0.33-0.38 | 0.70-0.90 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
4137 | 0.35-0.40 | 0.70-0.90 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
Mechanical Properties of ASME SA519 Steel Tubing
Grade Designation | Condition * | Ultimate Strength | Yield Strength | Elongation In 2in (%) | Rockwell Hardness B-Scale | ||
Ksi | Mpa | Ksi | Mpa | ||||
1020 | HR | 50 | 345 | 32 | 221 | 25 | 55 |
CW | 70 | 483 | 60 | 414 | 5 | 75 | |
SR | 65 | 448 | 50 | 345 | 10 | 72 | |
A | 48 | 331 | 28 | 193 | 30 | 50 | |
N | 55 | 379 | 34 | 234 | 22 | 60 | |
1025 | HR | 55 | 379 | 35 | 241 | 25 | 60 |
CW | 75 | 517 | 65 | 448 | 5 | 80 | |
SR | 70 | 483 | 55 | 379 | 8 | 75 | |
A | 53 | 365 | 30 | 207 | 25 | 57 | |
N | 55 | 379 | 36 | 248 | 22 | 60 | |
1035 | HR | 65 | 448 | 40 | 276 | 20 | 72 |
CW | 85 | 586 | 75 | 517 | 5 | 88 | |
SR | 75 | 517 | 65 | 448 | 8 | 80 | |
A | 60 | 414 | 33 | 228 | 25 | 67 | |
N | 65 | 448 | 40 | 276 | 20 | 72 | |
1045 | HR | 75 | 517 | 45 | 310 | 15 | 80 |
CW | 90 | 621 | 80 | 552 | 5 | 90 | |
SR | 80 | 552 | 70 | 483 | 8 | 85 | |
A | 65 | 448 | 35 | 241 | 20 | 72 | |
N | 75 | 517 | 48 | 331 | 15 | 80 | |
1050 | HR | 80 | 552 | 50 | 345 | 10 | 85 |
SR | 82 | 565 | 70 | 483 | 6 | 86 | |
A | 68 | 469 | 38 | 262 | 18 | 74 | |
N | 78 | 538 | 50 | 345 | 12 | 82 | |
4130 | HR | 90 | 621 | 70 | 483 | 20 | 89 |
SR | 105 | 724 | 85 | 586 | 10 | 95 | |
A | 75 | 517 | 55 | 379 | 30 | 81 | |
N | 90 | 621 | 60 | 414 | 20 | 89 | |
4140 | HR | 120 | 855 | 90 | 621 | 15 | 100 |
SR | 120 | 855 | 100 | 689 | 10 | 100 | |
A | 80 | 552 | 60 | 414 | 25 | 85 | |
N | 120 | 855 | 90 | 621 | 20 | 100 |
