Gautam tubes is a leading manufacturer of stainless steel products and exports a significant number of stainless steel products across the globe. Our company produces a different variety of steel products for applications in the steel industry. We have been producing top quality of Stainless Steel 321 Forged Fittings from a long time. Our products are reached to the customers in a considerable amount of time without any delay. The easy transportation of our products to the customers has led to good trust among our customers.
Our young and dynamic technical and the quality team strive for perfection continuously and ensure that no errors are created once the products are produced. Our company produces exceptional quality of steel products following industrial standards.
Forged pipe fittings can be defined as the elements or mechanisms which are used in pipe industry for connecting pipes with nominal bore diameter. Generally, it is seen that the fittings which are used in pipe industry have to work at high temperatures and pressure, so the pipes are mounted with forged fittings which helps in connecting pipes of different diameter and also forms a good connection with other pipes with varying diameters. The Stainless Steel 321 Forged Fittings are forged so that a strong fitting will be obtained in a steel pipe. The applications of forged fittings include chemical, petrochemical and power generation industries.
321 SS Forged Elbow, Stainless Steel ASTM A182 F321 Threaded Fittings Price List, Stainless Steel 321 45 Deg Socketweld Elbow, Stainless Steel 321 45 Deg Forged Elbow Distributors, ASTM A182 SS F321 Pipe Cap, Wrought Austenitic Stainless Steel 321 Industrial Forged Fittings Exporter in India.
FEATURES
Because of the stainless steel 321 forged fittings exceptional strength and industrial related properties, it is widely used in different industries. Properties of forged fittings are
• Higher corrosion resistance
• Lower maintenance
• Strength can be obtained through cold working
• The shine of steel gives a good appearance
• Hardness and strength are good
• It can be easily drawn into wires whenever the need arises
• Hot strength is very good
MANUFACTURING
The manufacturing of Stainless Steel 321 Forged Fittings is quite different than the other fittings. The stainless steel fittings get a touch of carbon steel as the corrosion properties of fittings get increased when carbon is added. Usually forging is used in which the fittings are manufactured by using compressive forces. Forging process adds good strength to the fittings so that the fittings could be able to withstand high temperature and pressure.
Standard Specification and Size Range of Stainless Steel 321 Forged Fittings
Specifications : ASTM A182 / ASME SA182
Dimensions : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
SS ASTM A182 F321 Elbow
SS 321 Forged Elbow, Stainless Steel 321 Threaded Elbow, UNS S32100 Socket Weld Elbow, DIN 1.4541 Forged Elbow, SS 321 45° Elbow, Stainless 321 90 deg Socketweld Elbow, A182 F321 180° Elbow
ASTM A182 F321 Tee
Stainless Steel 321 Threaded Tee, SS 1.4541 Forged Tee, UNS S32100 Equal Tee, SS 321 Unequal Tee, SS 321 Socketweld Tee, SS ASTM A182 F321 Unequal Tee, SS 321 Threaded Tee
SS 321 Full Coupling
Stainless Steel 321 Threaded Full Coupling, SUS 321 Socketweld Full Coupling, SS S32100 Forged Full Coupling, DIN 1.4541 Threaded Full Coupling
SS 321 Forged Half Coupling
SS 321 Threaded Half Coupling, ASTM A182 F321 Half Coupling, ANSI B16.11 SS 321 Forged Half Coupling, UNS S32100 Socketweld Half Coupling, Steel 1.4541 Threaded Half Coupling
SS 321 Forged Nipple
ASTM A182 F321 Socketweld Pipe Nipple, SS S32100 Threaded Pipe Nipple, Stainless Steel 321 Forged Swage Nipple, SS 321 Socketweld Hex Nipple, SUS 321 Threaded Pipe Nipple
Stainless Steel 321 Forged Cross
ASTM A182 F321 Equal Cross, SS 321 Unequal Cross, UNS S32100 Forged Cross, DIN 1.4541 Threaded Cross, ANSI B16.11 SS 321 Forged Cross, SS 321 Socketweld Cross
SS 321 Forged Union
ASTM A182 F321 Socketweld Union, SS S32100 Threaded Union, Stainless Steel 321 Forged Union, SS 321 Socketweld Union, SUS 321 Threaded Union
Stainless Steel 321 Bushing
ASTM A182 F321 Forged Bushing, SS 321 Threaded Bushing, UNS S32100 Forged Threaded Bushing, DIN 1.4541 Threaded Bushing, ANSI B16.11 SS 321 Hex Head Bushing, SS 321 Forged Bushing
SS 321 Forged Cap
ASTM A182 F321 Socketweld Cap, SS S32100 Threaded Cap, Stainless Steel 321 Forged Cap, SS 321 Socketweld Pipe Cap, SUS 321 Forged Pipe End Cap
Chemical Composition of Stainless Steel Grade 321 Forged Fittings
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Ti |
SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 - 12.00 | 5(C+N) – 0.70 max |
Mechanical Properties of ASTM A182 SS 321 Forged Fittings
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
People Also Searched For
stainless steel 321 half coupling, stainless steel 321 socketweld fittings manufacturers in india, stainless steel 321 short radius socketweld elbow – sr elbow, astm a182 f321 stainless steel socket weld fittings dimensions, schedule 10 stainless steel 321 forged fittings, stainless steel 321 forged equal tee stockholder, astm a182 ss 321 socketweld fittings manufacturer in mumbai, ss 321 forged fittings, ss 321 socketweld pipe nipple exporter in india, stainless steel 321 forged bushing, 321 stainless steel 45° short radius forged elbow, ss 321 union stockholder, 321 ss pipe nipple, 321 stainless steel socketweld equal cross traders, ss 321 threaded full coupling, ss 321 forged elbow, astm a182 f321 socketweld fittings price list, sus 321 threaded fitting, grade 321 stainless steel socket weld elbow, type 321 ss forged pipe end cap price, astm a182 f321 180° long & short radius threaded elbow, asme sa 182 stainless steel 321 forged bushing, ss 321 forged hex nipple dealers, stainless steel 321 forged elbow, stainless steel 321 Schedule 40 socketweld fittings, ss 321 threaded elbow, price of threaded pipe end cap stainless steel 321, aisi 321 forged fittings, astm a182 f321 fittings supplier in india, ss 321 90 deg forged long radius elbow, ss 321 socketweld fittings, ss 321 forged threaded fitting, buy best and high quality stainless steel 321 socketweld fittings at competitive price.
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- Grade 321 Stainless Steel Forged Fittings uses in Plumbing
- ASTM A182 F321 Stainless Steel Threaded Fittings uses in Heating
- ASTM A182 F321 Socketweld Fittings uses in Water Supply Systems
- SS 321 Forged Fittings uses in Paper & Pulp Industry
- 321 SS Forged Fittings uses in General Purpose Applications
- ASME SA182 Stainless Steel F321 Socketweld Fittings uses in Fabrication Industry
