Gautam tubes are manufacturer and supplier of a qualitative range of Stainless Steel 347H Forged Fittings. We are supplying these fittings in various standard and non standard dimensions. For multiple applications, we provide forged fittings in machining allowances and tolerance limits. Our products are followed under national internationals standards.
Stainless Steel 347H Forged Fittings are a balanced austenitic stainless steel forged fittings. It contains chromium and columbium content that takes into consideration because of end carbide precipitation and increase intergranular corrosion. These forged fittings have a higher composition of carbon that shows improved higher temperature and creeps properties.
These forged fittings have outstanding corrosion resistance properties similar to standard grades. These fittings are intended to use in chromium carbide precipitation between temperatures 427 deg C to 816 deg C. In this temperature range standard grade fittings are affected by intergranular attacks. It somewhat performs well in strong oxidizing conditions up to 816 deg C.
SS 347H forged fittings can be used in nitric solutions and most diluted organic acids at nominal temperatures in pure phosphoric acids at down temperatures.
ASTM A182 SS F347H Pipe Cap, 347H SS Forged Elbow, Stainless Steel ASTM A182 F347H Threaded Fittings Price List, Stainless Steel 347H 45 Deg Forged Elbow Distributors, Stainless Steel 347H 45 Deg Socketweld Elbow, Wrought Austenitic Stainless Steel 347H Industrial Forged Fittings Exporter in India.
It also opposes polythionic acid stress corrosion cracking. SS forged fittings can be used in fluoride and chloride free caustic solutions at nominal temperatures. However, these fittings do not offer good service in chloride containing environments even in small concentrations. Machining of stainless steel fittings is not tough it only requires standard feeds and speeds for machining.
DESCRIPTION
With all type of fusion and resistance welding, these forged fittings can be welded except gas welding. Forged fittings may or may not be welded by filler materials. the hot working operations are done in temperature between 1149 deg C to 1232 deg C. this material is recommended for hot working, forging or upsetting process. These forged fittings do not work above 927 deg C.
CONCLUSION
Stainless Steel 347H Forged Fittings must be water quenched or fully annealed after hot working to acquire maximum corrosion resistance. This operation also results in attaining maximum ductility. Hardening is not preferred by heat treatment operations; only cold working operations are performed to resolve this problem.
Standard Specification and Size Range of Stainless Steel 347H Forged Fittings
Specifications : ASTM A182 / ASME SA182
Dimensions : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
SS ASTM A182 F347H Elbow
SS 347H Forged Elbow, Stainless Steel 347H Threaded Elbow, UNS S34709 Socket Weld Elbow, DIN 1.4961 Forged Elbow, SS 347H 45° Elbow, Stainless 347H 90 deg Socketweld Elbow, A182 F347H 180° Elbow
ASTM A182 F347H Tee
Stainless Steel 347H Threaded Tee, SS 1.4961 Forged Tee, UNS S34709 Equal Tee, SS 347H Unequal Tee, SS 347H Socketweld Tee, SS ASTM A182 F347H Unequal Tee, SS 347H Threaded Tee
SS 347H Full Coupling
Stainless Steel 347H Threaded Full Coupling, SUS 347H Socketweld Full Coupling, SS S34709 Forged Full Coupling, DIN 1.4449Threaded Full Coupling
SS 347H Forged Half Coupling
SS 347H Threaded Half Coupling, ASTM A182 F347H Half Coupling, ANSI B16.11 SS 347H Forged Half Coupling, UNS S34709 Socketweld Half Coupling, Steel 1.4961 Threaded Half Coupling
SS 347H Forged Nipple
ASTM A182 F347H Socketweld Pipe Nipple, SS S34709 Threaded Pipe Nipple, Stainless Steel 347H Forged Swage Nipple, SS 347H Socketweld Hex Nipple, SUS 347H Threaded Pipe Nipple
Stainless Steel 347H Forged Cross
ASTM A182 F347H Equal Cross, SS 347H Unequal Cross, UNS S34709 Forged Cross, DIN 1.4961 Threaded Cross, ANSI B16.11 SS 347H Forged Cross, SS 347H Socketweld Cross
SS 347H Forged Union
ASTM A182 F347H Socketweld Union, SS S34709 Threaded Union, Stainless Steel 347H Forged Union, SS 347H Socketweld Union, SUS 347H Threaded Union
Stainless Steel 347H Bushing
ASTM A182 F347H Forged Bushing, SS 347H Threaded Bushing, UNS S34709 Forged Threaded Bushing, DIN 1.4961 Threaded Bushing, ANSI B16.11 SS 347H Hex Head Bushing, SS 347H Forged Bushing
SS 347H Forged Cap
ASTM A182 F347H Socketweld Cap, SS S34709 Threaded Cap, Stainless Steel 347H Forged Cap, SS 347H Socketweld Pipe Cap, SUS 347H Forged Pipe End Cap
Chemical Composition of Stainless Steel Grade 347H Forged Fittings
Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 20.00 | 8xC – 1.10 | 9.0 -13.0 | 63.72 min |
Mechanical Properties of ASTM A182 SS 347H Forged Fittings
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
