Gautam tubes are legally certified industry that has become specialized in offering the commendable quality of Stainless steel 321H forged fittings. We are today dealing at a large scale as a reliable and trustworthy manufacturer, exporter, supplier and stockiest. To meet the different requirements of the different industrialists we are providing the same at different specifications. It is provided to them at specifications that vary in sizes, designation, class, dimensions, and types, etc. It is also made available to them at cut-made specifications as per the demands they have made to us.
Alloy stainless steel 321H or UNS S32109 is the greater carbon version of the SS 321 alloy. It is developed to enhance the creep resistance and for the greater temperature service above 537 Deg C. In many cases, the carbon content is enabling double certifications.
The WNR 1.4878 forged fittings that are offered to the clients is having many good properties to offer. This is because of the addition of superior quality of alloy at the time of product development. Some of the good properties are-
• Good dimensional accuracy
• Holds high temperature
• Long serviceability
• Smoothness in surface finishes
• Anti-corrosive body
• Rugged construction
• Corrosion resistance
• Holds greater pressure
ASTM A182 SS F321H Pipe Cap, Stainless Steel 321H 45 Deg Socketweld Elbow, Stainless Steel ASTM A182 F321H Threaded Fittings Price List, 321H SS Forged Elbow, Stainless Steel 321H 45 Deg Forged Elbow Distributors, Wrought Austenitic Stainless Steel 321H Industrial Forged Fittings Exporter in India.
DESCRIPTION
The manufacturing process of Stainless steel 321H forged fittings starts by using the superior quality of alloy. The alloy that we are using is acquired from reliable market mills. The alloy used is 100% pure and is well tested and quality assured. The construction of these fittings is done under the tight supervision of professionals. They are using their skills and knowledge for guiding the workers at all level of product development so that the high quality of product development can be assured.
CONCLUSION
To add greater strength to the quality of S32109 forged fittings, we are doing the development by using sophisticated technology and modern tools. We are doing the fabrication of these fittings as per set manufacturing guidelines and national and international product quality standards. The quality checker team is there to check the quality of fittings to make sure that only the premium quality of fittings delivering is done.
Standard Specification and Size Range of Stainless Steel 321H Forged Fittings
Specifications : ASTM A182 / ASME SA182
Dimensions : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
SS ASTM A182 F321H Elbow
SS 321H Forged Elbow, Stainless Steel 321H Threaded Elbow, UNS S32109 Socket Weld Elbow, DIN 1.4541 Forged Elbow, SS 321H 45° Elbow, Stainless 321H 90 deg Socketweld Elbow, A182 F321H 180° Elbow
ASTM A182 F321H Tee
Stainless Steel 321H Threaded Tee, SS 1.4541 Forged Tee, UNS S32109 Equal Tee, SS 321H Unequal Tee, SS 321H Socketweld Tee, SS ASTM A182 F321H Unequal Tee, SS 321H Threaded Tee
SS 321H Full Coupling
Stainless Steel 321H Threaded Full Coupling, SUS 321H Socketweld Full Coupling, SS S32109 Forged Full Coupling, DIN 1.4541 Threaded Full Coupling
SS 321H Forged Half Coupling
SS 321H Threaded Half Coupling, ASTM A182 F321H Half Coupling, ANSI B16.11 SS 321H Forged Half Coupling, UNS S32109 Socketweld Half Coupling, Steel 1.4541 Threaded Half Coupling
SS 321H Forged Nipple
ASTM A182 F321H Socketweld Pipe Nipple, SS S32109 Threaded Pipe Nipple, Stainless Steel 321H Forged Swage Nipple, SS 321H Socketweld Hex Nipple, SUS 321H Threaded Pipe Nipple
Stainless Steel 321H Forged Cross
ASTM A182 F321H Equal Cross, SS 321H Unequal Cross, UNS S32109 Forged Cross, DIN 1.4541 Threaded Cross, ANSI B16.11 SS 321H Forged Cross, SS 321H Socketweld Cross
SS 321H Forged Union
ASTM A182 F321H Socketweld Union, SS S32109 Threaded Union, Stainless Steel 321H Forged Union, SS 321H Socketweld Union, SUS 321H Threaded Union
Stainless Steel 321H Bushing
ASTM A182 F321H Forged Bushing, SS 321H Threaded Bushing, UNS S32109 Forged Threaded Bushing, DIN 1.4541 Threaded Bushing, ANSI B16.11 SS 321H Hex Head Bushing, SS 321H Forged Bushing
SS 321H Forged Cap
ASTM A182 F321H Socketweld Cap, SS S32109 Threaded Cap, Stainless Steel 321H Forged Cap, SS 321H Socketweld Pipe Cap, SUS 321H Forged Pipe End Cap
Chemical Composition of Stainless Steel Grade 321H Forged Fittings
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Ti |
SS 321H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 - 12.00 | 4(C+N) – 0.70 max |
Mechanical Properties of ASTM A182 SS 321H Forged Fittings
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
People Also Searched For
stainless steel 321H forged equal tee stockholder, ss 321H forged threaded fitting, astm a182 ss 321H socketweld fittings manufacturer in mumbai, ss 321H 90 deg forged long radius elbow, stainless steel 321H forged elbow, ss 321H union stockholder, 321H ss pipe nipple, stainless steel 321H short radius socketweld elbow – sr elbow, astm a182 f321H 180° long & short radius threaded elbow, ss 321H threaded full coupling, 321H stainless steel socketweld equal cross traders, stainless steel 321H half coupling, ss 321H socketweld fittings, ss 321H forged fittings, ss 321H forged hex nipple dealers, aisi 321H forged fittings, stainless steel 321H socketweld fittings manufacturers in india, ss 321H threaded elbow, astm a182 f321H fittings supplier in india, astm a182 f321H socketweld fittings price list, stainless steel 321H Schedule 40 socketweld fittings, price of threaded pipe end cap stainless steel 321H, grade 321H stainless steel socket weld elbow, buy best and high quality stainless steel 321H socketweld fittings at competitive price, stainless steel 321H forged bushing, ss 321H socketweld pipe nipple exporter in india, schedule 10 stainless steel 321H forged fittings, 321H stainless steel 45° short radius forged elbow, asme sa 182 stainless steel 321H forged bushing, ss 321H forged elbow, type 321H ss forged pipe end cap price, sus 321H threaded fitting, astm a182 f321H stainless steel socket weld fittings dimensions.
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- Grade 321H Stainless Steel Forged Fittings uses in Plumbing
- ASTM A182 F321H Stainless Steel Threaded Fittings uses in Heating
- ASTM A182 F321H Socketweld Fittings uses in Water Supply Systems
- SS 321H Forged Fittings uses in Paper & Pulp Industry
- 321H SS Forged Fittings uses in General Purpose Applications
- ASME SA182 Stainless Steel F321H Socketweld Fittings uses in Fabrication Industry
