Gautam Tubes is well known for the production of high quality Stainless Steel 347H Pipes & Tubes. We are supplying SS pipes and tubes in bulk quantity and small quantity to national and international customers. Our only aim is to take confront from clients and fulfill their delights by our supplied product range. Regularly, we are enhancing and implementing the latest machinery in our manufacturing facility. We deal in other ferrous and non-ferrous pipes and tube related products. Our only focus is to deliver comprehensive piping and tubing solutions to our customers. For multiple uses, we make stainless steel pipes and tubes in various standards, specifications, and designations. Also, for a specific application, we produce products in altered dimensions too.
Stainless steel 347H is a stabilized austenitic and chromium steel containing alloy from 300 series. It allows for the protection from carbide precipitation range and consequently eliminated intergranular corrosion. Stainless steel is stabilized by the addition of tantalum and chromium. However, it offers elevated creep and stress rupture properties than its standard version. Stainless steel grade can be used for exposure in where sensitization is an issue. In addition to columbium, it allows having excellent corrosion resistance and even superior to its standard version. Stainless steel 347H is a higher carbon version that displays enhanced temperature properties.
Stainless Steel 347H Pipes & Tubes offer resistance to general and local corrosion. Generally, these are used for heavy welded equipment and cannot expose to annealing operations and exposure in temperature between 800 deg F to 150 deg F.
Stainless Steel 347H Instrumentation Tubing, Stainless Steel 347H ERW Pipe Price List, 347H SS Capillary Tube, SUS 347H Tubes, AISI 347H Pipes, SS 347H Seamless Tubing Distributors, SS 347H Heat Exchanger Tube Exporter in Mumbai.
Stainless Steel 347H Pipes & Tubes are recommended for low temperature and aqueous environments. These are primarily used in elevated temperature environments where sensitization is encountered. SS 347 H pipes and tubes are susceptible to stress corrosion cracking. As 18/8 austenitic pipes and tubes, it offer similar oxidation resistance. These pipes and tubes are considered to the most weldable, all common resistance and fusion welding can be used. Heat treatment temperature is 1800 deg F to 2000 deg F. may stress relieving is considered in precipitation range without any defects.
Standard Specification and Size Range of Stainless Steel 347H Pipe and Tube
Specifications for Stainless Steel 347H Pipe ASTM A312, A358 / ASME SA312, SA358
Specifications for Stainless Steel 347H Tube : ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554
Dimension Standard : ANSI B36.19M, ANSI B36.10
Outside Diameter of SS 347H Pipe : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock
Outside Diameter of SS 347H Tube : 1/8" OD TO 2"OD 3MM OD TO 38 MM OD
Thickness Range : 0.3mm – 50 mm, 1MM TO 3 MM 0.028 TO 0.156 IN, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Seamless Stainless Steel 347H Pipe Size : 1 / 2" NB - 16" NB
Welded Stainless Steel 347H Pipe Size : 1 / 2" NB - 16" NB
EFW Stainless Steel 347H Pipe Size : 6" NB - 24" NB
Type : Seamless / ERW / Welded / Fabricated
Length : Single Random, Double Random & Required Length
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Finish : 2B, No.4, No.1, No.8 Mirror Finish, or as per customer Requirements
Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
EN 10216-5 : EN 10216 Seamless Steel 347H Tubes, EN 10216-5 1.4961 Seamless Stainless Steel Tube for pressure purposes
EN 10217-7 : EN 10217 Welded Stainless Steel 347H Tubes, Steel EN 10217-7 1.4961 Welded Tube for pressure purposes
Stainless Steel 347H Seamless Pipes
SS 347H Seamless Pipe, UNS S34709 Seamless Pipes, DIN 1.4961 Seamless Pipe, ASTM A312 TP347H Seamless Pipes
Stainless Steel 347H Seamless Tubes
SS 347H Seamless Tube, UNS S34709 Seamless Tubes, SS 1.4961 Seamless Tubes, ASTM A213 TP347H Seamless Tubing
Stainless Steel 347H Welded Pipes
SS 347H Welded Pipes, SS S34709 Welded Pipe, SS 1.4961 Welded Pipes, ASTM A312 TP347H Stainless Steel Welded Pipes
Stainless Steel 347H Welded Tubes
SS 347H Welded Tube, Stainless Steel S34709 Welded Tubes, DIN 1.4961 Welded Tubing, ASME SA 249 TP347H Stainless Steel Welded Tubes
Stainless Steel 347H ERW Pipes
Stainless Steel S34709 ERW Pipes, SS 1.4961 ERW Pipes, ASME SA312 TP347H Stainless Steel ERW Pipes, SS 347H ERW Pipes
Stainless Steel 347H ERW Tubes
SS S34709 ERW Tubes, Stainless Steel 1.4961 ERW Tubes, ASME SA312 TP347H Stainless Steel ERW Tubes, SS 347H ERW Tubing
Stainless Steel 347H EFW Pipes
UNS S34709 EFW Pipes, Stainless Steel 1.4961 EFW Pipes, ASME SA358 TP347H Stainless Steel EFW Pipes, SS 347H EFW Pipes
Chemical Composition of Stainless Steel Grade 347H Pipes & Tubes
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
SS 347H | 13.00 / 9.00 max | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 20.0 /17.0 max | - | 1.0 / Nb=10(C+N) |
Mechanical Properties of ASME SA312 Stainless Steel 347H Pipes / SA213 Stainless Steel 347H Tubing
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35% Max. |
People Also Searched For
stainless steel 347h pipe suppliers, ss 347h pipe price, stainless steel pipe aisi 347h, stainless steel pipe 347h grade weight, 3 inch steel 347h pipe price, 347h ss sanitary tubing, austenitic stainless steel 347h tubes, stainless steel 347h pipes dimensions, schedule 40 stainless steel 347h pipe dimensions, stainless steel 347h pipe thickness, stainless steel 347h pipe thickness, stainless steel 347h pipes for sale, jindal stainless steel 347h tubes, austenitic stainless steel 347h pipes, stainless steel pipe 347h price per kg manufacturers india, electric resistance welded stainless steel 347h pipe and tube, stainless steel 347h pipe gauge chart, price of stainless steel 347h pipes, ss 347h mechanical tubing, ss 347h condenser tubes, 347h stainless steel pipe working pressure, stainless steel 347h pipe price list in india, stainless steel 347h tubes price list in india, stainless steel 347h boiler tubes, stainless steel 347h pipe weight, 347h stainless steel pipe specifications, jindal steel pipe 347h price, stainless steel 347h tubes dimensions, jindal ss 347h pipe weight chart, sizes of stainless steel 347h pipes, stainless steel 347h pipes exporter, weight of ss 347h pipe schedule 10, stainless steel 347h pipe price per kg in india, schedule 10 ss 347h pipe thickness, stainless steel tube grade 347h, 347h schedule 10 stainless steel, stainless steel 347h tube suppliers, ss 347h seamless tube price, stainless steel 347h heat-exchanger tubes, jindal stainless steel 347h pipes, stainless steel 347h pipe weight chart, 347h stainless steel pipe schedule 80, stainless steel 347h tubing gauge chart, ss 347h tube sizes india, asme sa 213 tp 347h stainless steel tubes, asme sa 312 tp347h stainless steel pipes dealer, stainless steel 347h u shaped tubes, 347h stainless steel tube specifications, stainless steel 347h tubes weight chart, ss 347h seamless pipe sizes, 347h ss guage pipes, electric-fusion-welded austenitic stainless steel 347h pipe, stainless steel 347h tubes prices, stainless steel 347h pipes supplier in india, seamless and welded austenitic stainless steel tubing grade 347h, 347h stainless steel pipe chemical composition, stainless steel 347h electropolished pipes, stainless steel 347h pipe specifications astm, ss 347h pipe price per meter, 347h stainless steel pipes in mumbai, jindal stainless steel 347h welded pipes, standard schedule 10s stainless steel pipe 347h, stainless steel 347h superheater tube, stainless steel 347h pipes diameters, grade 347h stainless steel pipes and tubes manufacturer in india, ss 347h pipe, stainless steel 347h tube diameters, 347h stainless steel pipe specifications pdf, 347h stainless steel pipe price list, ss 347h electro polished tubes, ss 347h finned tube .
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- ASTM A312 TP347H Stainless Steel Pipe uses in Plumbing
- ASTM A213 TP347H Stainless Steel Tube uses in Heating
- Stainless Steel 347H Pipes & Tubes uses in Water Supply Systems
- 347H Stainless Steel Pipes & Tubes uses in Paper & Pulp Industry
- Stainless Steel 347H Welded Pipes and Tubes uses in General Purpose Applications
- SS 347H Seamless Pipes and Tubes uses in Fabrication Industry
