Gautam Tubes is involved in manufacturing and supplying the high quality of Stainless Steel 304L Sheets and Plates. We are taking full care of the needs of our esteem patrons and thus to satisfy all their needs of sheets and plates we offer them in varying specifications. We are offering SS sheets and plates in various wall thickness, sizes, standards, etc. It is too manufactured and offered to the clients at custom-made same as per the demands the clients have made.
304L is having the resistance to oxidation ability to a maximum temperature of 899 Deg C constantly without appreciating scaling. The maximum temperature is 816 Deg C for intermittent exposure. As 304L is the extra low carbon variation of alloy 304 and it can be used often into the as-weld condition with no annealing in the highly corrosive atmosphere, except for the application that specifying stress relief. Alloy 304L is having very good welding property and it can be welded through all the standard techniques but proper attention must be given for avoiding the hot cracking. Welding can be followed through annealing for relieving stress at the time of severe forming or spinning.
The development of Stainless Steel 304L Sheets and Plates at our highly operational manufacturing unit is done under the tight supervision of experts. They are guiding the workers at all level of production stages to develop the superior quality of sheets/plates. We are using the refined technology and modern tools for the development of SS 304L sheets and plates to make sure that product come out could assure perfect dimensions and smoothness in finishes.
304L SS Coils, Austenitic Stainless Steel 304L Perforated Sheets Distributors, SS 304L 2B Finish Sheets, Stainless Steel 304L Hot Rolled Plates, Stainless Steel 304L Sheets Price List, ASTM A240 SS 304L Sheets & Plates Exporter in India.
To fabricate the product of high quality we are making the effective use of superior quality of alloy that is sourced from best market vendors and the alloy is well tested and certified for use in the product development. The quality checker team is hired that is looking at the product quality standards to make sure that we only develop the fine quality of sheets/plates. Complete ranges of 304L plates/sheets offered to the clientele are developed according to the set production norms and raw material quality standards.
Standard Specification and Size Range of Stainless Steel 304L Sheets & Plates
Specifications : ASTM A240 / ASME SA240
Dimensions : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
ASTM A240 304L SS Perforated Sheets
SS 304L Perforated Sheet, Stainless Steel 304L Perforated Sheets, UNS S30403 Perforated Sheets, DIN 1.4306 Perforated Sheets, Stainless 304L Perforated Sheets
ASTM A240 304L SS Chequered Plates
Stainless Steel 304L Chequered Plates, SS 1.4306 Chequered Plates, UNS S30403 Chequered Plates, SS 304L Checkered Plates
ASTM A240 304L SS Shim Sheets
Stainless Steel 304L Shim Sheets, SUS 304L Shim Sheets, SS S30403 Shim Sheets, DIN 1.4306 Shim Sheets
Chemical Composition of Stainless Steel Grade 304L Sheets & Plates
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | - | 8 – 13 | - |
Mechanical Properties of ASTM A240 SS 304L Sheets & Plates
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
People Also Searched For
stainless steel 304L sheets supplier, 304L ss coils, buy best and high quality stainless steel 304L sheets at competitive price, type 304L ss sheets price, astm a240 ss 304L sheets manufacturer in mumbai, grade 304L stainless steel perforated sheets, schedule 10 stainless steel 304L 2b finish plates, ss 304L coils, astm a240 304L stainless steel sheets dimensions, 304L stainless steel perforated sheets traders, ss 304L checker plates, price of sheets and plates stainless steel 304L, ss 304L checkered plates, stainless steel 304L ba finish cold rolled sheet manufacturers in india, ss 304L sheets dealers, ss 304L hot rolled plates exporter in india, astm a240 304L plates supplier in india, ss 304L foils, ss 304L plain sheets, ss 304L coil stockholder, astm a240 304L strips price list, stainless steel 304L slitting coil, asme sa 240 stainless steel 304L plates, stainless steel 304L mirror sheets, sus 304L hot rolled plates, 304L stainless steel plates, stainless steel 304L sheets stockholder, ss 304L plates, astm a240 304L sheet, aisi 304L cold rolled sheets, ss 304L chequered plates, stainless steel 304L sheet / plate / coil.
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- Grade 304L Stainless Steel Sheets uses in Plumbing
- ASTM A240 304L Stainless Steel Plates uses in Heating
- ASTM A240 304L Sheets uses in Water Supply Systems
- SS 304L Coil uses in Paper & Pulp Industry
- 304L SS Plates uses in General Purpose Applications
- ASME SA240 Stainless Steel 304L Sheets uses in Fabrication Industry
