Gautam Tubes is the top-ranking manufacturer, exporter, supplier of the commendable quality of comprehensive ranges of Stainless steel 347 Sheets and plates. We are engaged in offering the superior quality of SS sheets/plates to the clients so that all demands of various industrial applications could get easily satisfied.
It is offered to the clients at various standard specifications that vary in standards, sizes, hardness, wall thickness, finishes, forms, etc. To the national and international clients, we are providing these sheets and plates at custom-made specifications as per the demands they are having. The product is delivered to the clients only once it is well quality checked and approved.
Stainless steel 347 alloy is chromium stabilized austenitic steel that is having columbium that permits the elimination of carbide precipitations and intergranular corrosion. Alloy SS 347 is stabilized by the addition of alloys like tantalum and chromium and is thus offering high creep and stress rupture properties than other alloys that can be used for the exposures wherein intergranular as well as sensitization is concerns. The addition of columbium permits alloys SS 347 to have very good resistance to corrosion.
347 SS Coils, Stainless Steel 347 Sheets Price List, Stainless Steel 347 Hot Rolled Plates, Austenitic Stainless Steel 347 Perforated Sheets Distributors, SS 347 2B Finish Sheets, ASTM A240 SS 347 Sheets & Plates Exporter in India.
PROPERTIES
All our fabricated ranges of Stainless steel 347 Sheets and plates are having many good properties to offer, making our product an ideal choice for various applications. The properties our product is having are-
• Rugged construction
• Pitting and oxidation resistance
• Good dimensional accuracy
• Holds high temperature
• Sturdiness
• Holds high pressure
• Longevity
• Rust resistance
QUALITY
The development of these Stainless steel 347 Sheets and plates are done at our manufacturing by effectively using the premium quality of alloy. The alloy that we use is collected from reliable mills and is tested by the quality checker team before used. The use of sophisticated technology and modern tools has allowed us to add high strength and greater superiority in the quality of sheets and plates. We are doing the development of the WNR 1.4550 sheets/plates as per set production guidelines and manufacturing norms. Additionally to check the purity of SS 347 sheets/plates the quality checker team is there to check the product quality.
Standard Specification and Size Range of Stainless Steel 347 Sheets & Plates
Specifications : ASTM A240 / ASME SA240
Dimensions : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
ASTM A240 347 SS Perforated Sheets
SS 347 Perforated Sheet, Stainless Steel 347 Perforated Sheets, UNS S34700 Perforated Sheets, DIN 1.4550 Perforated Sheets, Stainless 347 Perforated Sheets
ASTM A240 347 SS Chequered Plates
Stainless Steel 347 Chequered Plates, SS 1.4550 Chequered Plates, UNS S34700 Chequered Plates, SS 347 Checkered Plates
ASTM A240 347 SS Shim Sheets
Stainless Steel 347 Shim Sheets, SUS 347 Shim Sheets, SS S34700 Shim Sheets, DIN 1.4550 Shim Sheets
Chemical Composition of Stainless Steel Grade 347 Sheets & Plates
Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 20.00 | 10xC – 1.10 | 9.00 - 13.00 | 62.74 min |
Mechanical Properties of ASTM A240 SS 347 Sheets & Plates
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
People Also Searched For
stainless steel 347 sheets supplier, price of sheets and plates stainless steel 347, buy best and high quality stainless steel 347 sheets at competitive price, stainless steel 347 sheet / plate / coil, asme sa 240 stainless steel 347 plates, ss 347 hr plates, astm a240 347 sheet, ss 347 hot rolled plates exporter in india, ss 347 checker plates, stainless steel 347 sheet, ss 347 checkered plates, stainless steel 347 sheets stockholder, astm a240 ss 347 sheets manufacturer in mumbai, ss 347 coils, ss 347 slit coils, astm a240 347 plates supplier in india, ss 347 sheets dealers, sus 347 hot rolled plates, type 347 ss sheets price, 347 ss coils, stainless steel 347 ba finish cold rolled sheet manufacturers in india, astm a240 347 strips price list, ss 347 slitting coils, ss 347 plates, ss 347 coil stockholder, 347 stainless steel plates, 347 stainless steel perforated sheets traders, astm a240 347 stainless steel sheets dimensions, grade 347 stainless steel perforated sheets, aisi 347 cold rolled sheets, schedule 10 stainless steel 347 2b finish plates, stainless steel 347 plain sheets.
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- Grade 347 Stainless Steel Sheets uses in Plumbing
- ASTM A240 347 Stainless Steel Plates uses in Heating
- ASTM A240 347 Sheets uses in Water Supply Systems
- SS 347 Coil uses in Paper & Pulp Industry
- 347 SS Plates uses in General Purpose Applications
- ASME SA240 Stainless Steel 347 Sheets uses in Fabrication Industry
