Gautam Tubes is the leading manufacturer, exporter and supplier Stainless Steel 304L Pipes & Tubes in the global market. We are offering a wide ranges of the 304L Stainless Steel Pipes & Tubes to our patrons. We had established our organization in 1984 which was started to produce large ranges of the ferrous and non-ferrous materials. This ferrous and non-ferrous material is widely used by all the core industries. Our manufactured SS 304L pipes & tubes are extensively known for its excellent tensile and material strength, it is also offered as per the demand of the clients.
SS 304L is the austenitic stainless steel which has low carbon content than the other grades of stainless steel. Because of the high contents of chromium present in the 304L stainless steel it is known for its corrosion resistance ability. The alloy can be kept in the annealed environment as it contains low carbon contents. These alloys often resist corrosion that is the reason why it is largely used in the food processing industries. The alloy 304L is largely used in the manufacturing of the Stainless Steel 304L Pipes & Tubes delivered to the clients.
The 304L SS pipes & tubes manufactured contains many characteristics. Different characteristics of the Stainless Steel 304L Pipes & Tubes are excellent corrosion resistance due to the presence of low carbon content, strong tensile strength and good toughness that the product acquires from the whole manufacturing process. The SS 304L pipes & tubes also contains excellent weldability and machinability which enables the easy production. Because of these characteristics the pipes & tubes are used among all the industries.
SUS 304L Tubes, AISI 304L Pipes, Stainless Steel 304L ERW Pipe Price List, SS 304L Seamless Tubing Distributors, 304L SS Capillary Tube, Stainless Steel 304L Instrumentation Tubing, SS 304L Heat Exchanger Tube Exporter in Mumbai.
The good quality of the Stainless Steel 304L Pipes & Tubes is manufactured by using the pure alloy without any harmful particles. So, that 304L SS Pipes & tubes of superior quality are served to the well-recognized clients. The SS 304L pipes & tubes is widely used among the industries which are working in the high temperature environment. They are mainly used in the industries such as oil and gas, pulp and paper, petrochemical and many more.
Standard Specification and Size Range of Stainless Steel 304L Pipe and Tube
Specifications for Stainless Steel 304L Pipe ASTM A312, A358 / ASME SA312, SA358
Specifications for Stainless Steel 304L Tube : ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554
Dimension Standard : ANSI B36.19M, ANSI B36.10
Outside Diameter of SS 304L Pipe : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock
Outside Diameter of SS 304L Tube : 1/8" OD TO 2"OD 3MM OD TO 38 MM OD
Thickness Range : 0.3mm – 50 mm, 1MM TO 3 MM 0.028 TO 0.156 IN, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Seamless Stainless Steel 304L Pipe Size : 1 / 2" NB - 16" NB
Welded Stainless Steel 304L Pipe Size : 1 / 2" NB - 24" NB
EFW Stainless Steel 304L Pipe Size : 6" NB - 24" NB
Type : Seamless / ERW / Welded / Fabricated
Length : Single Random, Double Random & Required Length
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Finish : 2B, No.4, No.1, No.8 Mirror Finish, or as per customer Requirements
Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
EN 10216-5 : EN 10216 Seamless Steel 304L Tubes, EN 10216-5 1.4307 Seamless Stainless Steel Tube for pressure purposes
EN 10217-7 : EN 10217 Welded Stainless Steel 304L Tubes, Steel EN 10217-7 1.4307 Welded Tube for pressure purposes
Stainless Steel 304L Seamless Pipes
SS 304L Seamless Pipe, UNS S30403 Seamless Pipes, DIN 1.4307 Seamless Pipe, ASTM A312 TP304L Seamless Pipes
Stainless Steel 304L Seamless Tubes
SS 304L Seamless Tube, UNS S30403 Seamless Tubes, SS 1.4307 Seamless Tubes, ASTM A213 TP304L Seamless Tubing
Stainless Steel 304L Welded Pipes
SS 304L Welded Pipes, SS S30403 Welded Pipe, SS 1.4307 Welded Pipes, ASTM A312 TP304L Stainless Steel Welded Pipes
Stainless Steel 304L Welded Tubes
SS 304L Welded Tube, Stainless Steel S30403 Welded Tubes, DIN 1.4307 Welded Tubing, ASME SA 249 TP304L Stainless Steel Welded Tubes
Stainless Steel 304L ERW Pipes
Stainless Steel S30403 ERW Pipes, SS 1.4307 ERW Pipes, ASME SA312 TP304L Stainless Steel ERW Pipes, SS 304L ERW Pipes
Stainless Steel 304L ERW Tubes
SS S30403 ERW Tubes, Stainless Steel 1.4307 ERW Tubes, ASME SA312 TP304L Stainless Steel ERW Tubes, SS 304L ERW Tubing
Stainless Steel 304L EFW Pipes
UNS S30403 EFW Pipes, Stainless Steel 1.4307 EFW Pipes, ASME SA358 TP304L Stainless Steel EFW Pipes, SS 304L EFW Pipes
Chemical Composition of Stainless Steel Grade 304L Pipes & Tubes
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | - | 8 – 13 | - |
Mechanical Properties of ASME SA312 Stainless Steel 304L Pipes / SA213 Stainless Steel 304L Tubing
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
People Also Searched For
asme sa 312 tp304l stainless steel pipes dealer, stainless steel 304l u shaped tubes, stainless steel 304l pipe weight chart, stainless steel 304l tubing gauge chart, stainless steel 304l pipe suppliers, 304l stainless steel tube specifications, ss 304l pipe price, jindal ss 304l pipe weight chart, stainless steel 304l pipe thickness, electric-fusion-welded austenitic stainless steel 304l pipe, jindal stainless steel 304l welded pipes, 304l stainless steel pipe specifications, ss 304l pipe price per meter, jindal stainless steel 304l pipes, stainless steel pipe 304l price per kg, stainless steel 304l superheater tube, stainless steel 304l tubes price list in india, stainless steel 304l tubes dimensions, sizes of stainless steel 304l pipes, 304l stainless steel pipe price list, 304l stainless steel pipes in mumbai, stainless steel 304l pipes supplier in india, stainless steel 304l pipes diameters, stainless steel 304l pipes exporter, ss 304l pipe manufacturers india, stainless steel 304l pipe gauge chart, stainless steel 304l pipe specifications astm, 3 inch steel 304l pipe price, stainless steel 304l pipes dimensions, stainless steel 304l pipes for sale, electric resistance welded stainless steel 304l pipe and tube, stainless steel 304l heat-exchanger tubes, 304l stainless steel pipe working pressure, 304l schedule 10 stainless steel, stainless steel 304l pipe thickness, jindal steel pipe 304l price, stainless steel 304l pipe price per kg in india, grade 304l stainless steel pipes and tubes manufacturer in india, 304l ss sanitary tubing, 304l stainless steel pipe schedule 80, austenitic stainless steel 304l tubes, seamless and welded austenitic stainless steel tubing grade 304l, stainless steel 304l electropolished pipes, stainless steel pipe aisi 304l, stainless steel 304l tube diameters, stainless steel 304l tubes prices, ss 304l finned tube, ss 304l tube sizes india, 304l stainless steel pipe specifications pdf, schedule 10 ss 304l pipe thickness, asme sa 213 tp 304l stainless steel tubes, ss 304l electro polished tubes, stainless steel pipe 304l grade weight, ss 304l mechanical tubing, jindal stainless steel 304l tubes, schedule 40 stainless steel 304l pipe dimensions, austenitic stainless steel 304l pipes, stainless steel 304l pipe weight, price of stainless steel 304l pipes, 304l ss guage pipes, stainless steel 304l tubes weight chart, stainless steel 304l pipe price list in india, stainless steel tube grade 304l, 304l stainless steel pipe chemical composition, ss 304l seamless pipe sizes, stainless steel 304l tube suppliers, ss 304l seamless tube price, standard schedule 10s stainless steel pipe 304l, weight of ss 304l pipe schedule 10, stainless steel 304l boiler tubes, ss 304l condenser tubes.
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- ASTM A312 TP304L Stainless Steel Pipe uses in Plumbing
- ASTM A213 TP304L Stainless Steel Tube uses in Heating
- Stainless Steel 304L Pipes & Tubes uses in Water Supply Systems
- 304L Stainless Steel Pipes & Tubes uses in Paper & Pulp Industry
- Stainless Steel 304L Welded Pipes and Tubes uses in General Purpose Applications
- SS 304L Seamless Pipes and Tubes uses in Fabrication Industry
