As a globally acclaimed industry, Gautam Tubes is leading on the top for dealing as a trustworthy manufacturer, supplier, and exporter. We as having the good years of working knowledge are thus able to offer the superior quality of comprehensive ranges of Stainless Steel 347 pipes & tubes. We have today expanded our market throughout the globe and thus our offered product ranges reach to every client. UNS S34700 pipes/tubes are offered to the clients are varying in specifications like standards, dimensions, sizes, wall thickness, types, forms, end, length, etc. Also based upon the demand of the clients we are offering the product to them at custom-made specifications.
Alloy stainless steel 347 is having little bit well-enhanced corrosion resistance over other alloys into the strongly oxidizing atmosphere. Alloy SS 347 is the tantalum and columbium stabilized nickel-chromium austenitic stainless steel that is created for providing the 18/8 type alloy with very well enhanced improvised resistance ability against Intergranular corrosion. This alloy is having very good corrosion resistance ability over other alloys of stainless steel into the strongly oxidizing atmosphere resulting from the addition of tantalum and columbium.
Tantalum-columbium carbide precipitates within the grain instead of grain boundary formations. It is considered for the applications that need intermittent heating between temperature 800 Deg F and 899 Deg C or for the welding under the conditions that result in preventing the post-weld annealing. All our provided ranges of SS 347 pipes/tubes are having many good properties to offer including high tensile strength, rugged construction. Additional features include general corrosion resistance, hold high temperature, non-corrosive body, long-lasting properties etc.
SUS 347 Tubes, Stainless Steel 347 Instrumentation Tubing , Stainless Steel 347 ERW Pipe Price List, AISI 347 Pipes, 347 SS Capillary Tube, SS 347 Heat Exchanger Tube Distributors, SS 347 Seamless Tubing Exporter in Mumbai.
The manufacturing process of Stainless Steel 347 pipes & tubes begins up with the effective use of superior quality of alloy. The alloy that we are using is acquired from the right mills and is well tested and quality approved. Professionals are guiding the workers at all level to develop the commendable quality of tubes/pipes. We are designing those as per set national and international product quality standards and manufacturing norms addition to the use of refined technology and modern tools.
Standard Specification and Size Range of Stainless Steel 347 Pipe and Tube
Specifications for Stainless Steel 347 Pipe ASTM A312, A358 / ASME SA312, SA358
Specifications for Stainless Steel 347 Tube : ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554
Dimension Standard : ANSI B36.19M, ANSI B36.10
Outside Diameter of SS 347 Pipe : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock
Outside Diameter of SS 347 Tube : 1/8" OD TO 2"OD 3MM OD TO 38 MM OD
Thickness Range : 0.3mm – 50 mm, 1MM TO 3 MM 0.028 TO 0.156 IN, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Seamless Stainless Steel 347 Pipe Size : 1 / 2" NB - 16" NB
Welded Stainless Steel 347 Pipe Size : 1 / 2" NB - 16" NB
EFW Stainless Steel 347 Pipe Size : 6" NB - 24" NB
Type : Seamless / ERW / Welded / Fabricated
Length : Single Random, Double Random & Required Length
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Finish : 2B, No.4, No.1, No.8 Mirror Finish, or as per customer Requirements
Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
EN 10216-5 : EN 10216 Seamless Steel 347 Tubes, EN 10216-5 1.4550 Seamless Stainless Steel Tube for pressure purposes
EN 10217-7 : EN 10217 Welded Stainless Steel 347 Tubes, Steel EN 10217-7 1.4550 Welded Tube for pressure purposes
Stainless Steel 347 Seamless Pipes
SS 347 Seamless Pipe, UNS S34700 Seamless Pipes, DIN 1.4550 Seamless Pipe, ASTM A312 TP347 Seamless Pipes
Stainless Steel 347 Seamless Tubes
SS 347 Seamless Tube, UNS S34700 Seamless Tubes, SS 1.4550 Seamless Tubes, ASTM A213 TP347 Seamless Tubing
Stainless Steel 347 Welded Pipes
SS 347 Welded Pipes, SS S34700 Welded Pipe, SS 1.4550 Welded Pipes, ASTM A312 TP347 Stainless Steel Welded Pipes
Stainless Steel 347 Welded Tubes
SS 347 Welded Tube, Stainless Steel S34700 Welded Tubes, DIN 1.4550 Welded Tubing, ASME SA 249 TP347 Stainless Steel Welded Tubes
Stainless Steel 347 ERW Pipes
Stainless Steel S34700 ERW Pipes, SS 1.4550 ERW Pipes, ASME SA312 TP347 Stainless Steel ERW Pipes, SS 347 ERW Pipes
Stainless Steel 347 ERW Tubes
SS S34700 ERW Tubes, Stainless Steel 1.4550 ERW Tubes, ASME SA312 TP347 Stainless Steel ERW Tubes, SS 347 ERW Tubing
Stainless Steel 347 EFW Pipes
UNS S34700 EFW Pipes, Stainless Steel 1.4550 EFW Pipes, ASME SA358 TP347 Stainless Steel EFW Pipes, SS 347 EFW Pipes
Chemical Composition of Stainless Steel Grade 347 Pipes & Tubes
Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 20.00 | 10xC – 1.10 | 9.00 - 13.00 | 62.74 min |
Mechanical Properties of ASME SA312 Stainless Steel 347 Pipes / SA213 Stainless Steel 347 Tubing
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
People Also Searched For
stainless steel 347 pipe suppliers, ss 347 pipe price, stainless steel pipe aisi 347, stainless steel pipe 347 grade weight, 3 inch steel 347 pipe price, 347 ss sanitary tubing, austenitic stainless steel 347 tubes, stainless steel 347 pipes dimensions, schedule 40 stainless steel 347 pipe dimensions, stainless steel 347 pipe thickness, stainless steel 347 pipe thickness, stainless steel 347 pipes for sale, jindal stainless steel 347 tubes, austenitic stainless steel 347 pipes, stainless steel pipe 347 price per kg manufacturers india, electric resistance welded stainless steel 347 pipe and tube, stainless steel 347 pipe gauge chart, price of stainless steel 347 pipes, ss 347 mechanical tubing, ss 347 condenser tubes, 347 stainless steel pipe working pressure, stainless steel 347 pipe price list in india, stainless steel 347 tubes price list in india, stainless steel 347 boiler tubes, stainless steel 347 pipe weight, 347 stainless steel pipe specifications, jindal steel pipe 347 price, stainless steel 347 tubes dimensions, jindal ss 347 pipe weight chart, sizes of stainless steel 347 pipes, stainless steel 347 pipes exporter, weight of ss 347 pipe schedule 10, stainless steel 347 pipe price per kg in india, schedule 10 ss 347 pipe thickness, stainless steel tube grade 347, 347 schedule 10 stainless steel, stainless steel 347 tube suppliers, ss 347 seamless tube price, stainless steel 347 heat-exchanger tubes, jindal stainless steel 347 pipes, stainless steel 347 pipe weight chart, 347 stainless steel pipe schedule 80, stainless steel 347 tubing gauge chart, ss 347 tube sizes india, asme sa 213 tp 347 stainless steel tubes, asme sa 312 tp347 stainless steel pipes dealer, stainless steel 347 u shaped tubes, 347 stainless steel tube specifications, stainless steel 347 tubes weight chart, ss 347 seamless pipe sizes, 347 ss guage pipes, electric-fusion-welded austenitic stainless steel 347 pipe, stainless steel 347 tubes prices, stainless steel 347 pipes supplier in india, seamless and welded austenitic stainless steel tubing grade 347, 347 stainless steel pipe chemical composition, stainless steel 347 electropolished pipes, stainless steel 347 pipe specifications astm, ss 347 pipe price per meter, 347 stainless steel pipes in mumbai, jindal stainless steel 347 welded pipes, standard schedule 10s stainless steel pipe 347, stainless steel 347 superheater tube, stainless steel 347 pipes diameters, grade 347 stainless steel pipes and tubes manufacturer in india, ss 347 pipe, stainless steel 347 tube diameters, 347 stainless steel pipe specifications pdf, 347 stainless steel pipe price list, ss 347 electro polished tubes, ss 347 finned tube .
Oil and Gas
Chemical Industry
Power Plant
Food Industry
Petrochemical
Automobile
Application Industries
- ASTM A312 TP347 Stainless Steel Pipe uses in Plumbing
- ASTM A213 TP347 Stainless Steel Tube uses in Heating
- Stainless Steel 347 Pipes & Tubes uses in Water Supply Systems
- 347 Stainless Steel Pipes & Tubes uses in Paper & Pulp Industry
- Stainless Steel 347 Welded Pipes and Tubes uses in General Purpose Applications
- SS 347 Seamless Pipes and Tubes uses in Fabrication Industry
